Description

Inspired and officially licensed from Teia's Stochastic Function Generator which was introduced in 2013 but is no longer available. We used the concept of the early version but completely rebuilt and reprogrammed it's mcu to a fully featured 4 voice 2 stage envelope and slew generator.

This new module + expansion is our take on a different envelope/slew generator. It's a fully featured Quad Analogue Core Envelope Generator and Slew Processor with digital control which also incorporates built-in random generators to control the Rise and Fall times.
Covering the full range from short sharp notes to long slow sweeps of up to 6 minutes. Together with the random generators it excels when used for drone soundscapes.
Used as a Slew Processor the random generators act as dynamic modulation sources affecting the rise and fall slew speed.
Fully featured outputs act as encouragement to self-patching creating interdependent envelopes acting in sync.

SPECS
Width: 20HP
Depth: 40mm
Power: 200mA +12V, 150mA -12v

CV OUTPUT RANGE
Each channel CV output range can be set with the [Amplitude] and [Offset] attenuverters.
Amplitude can be set to a maximum of 10v peak to peak(pp), ex 0 to +10v or -5v to +5v.
Offset can as a maximum range of 20v peak to peak and allows to offset the CV to ±10v.
