Name: NLM CV Polymorpher – cardOC T4.0 208 card [Buchla Compatible]
Brand: Northern Light Modular
Price: 885.00 USD

4U-B

Product formNorthern Light Modular

NLM CV Polymorpher – cardOC T4.0 208 card [Buchla Compatible]

The all new Teensy 4.0 powered cardOC Compatible with all 208 models, utilizing the full power of the PHAZERVILLE suite cardOC T4.0... Read more Read more

Description

The all new Teensy 4.0 powered cardOC

Compatible with all 208 models, utilizing the full power of the PHAZERVILLE suite

cardOC T4.0 features :

4 channel, dual applet control voltage processor
Horizontal mounting style to accommodate the slanted Command boat.
Individual pitch control directly through the bus for MO and CO.
24 switchable modulation sources and targets.
Easel command specific MIDI inputs for pitch and trigger inputs for both channels.
Phazerville powered multi applet software suite.
Buffered inputs – allowing to use both the card bus CV and external CV by adding the values into one combined control voltage.
Buffered outputs, allowing the card to drive multiple CV targets without losing pitch tracking.

New Crimes

Up to 16 Presets in the new Hemisphere Config
Modal-editing style cursor navigation (and other usability tweaks)
Expanded internal Clock Setup
New Apps: Scenes and Calibr8or

New Applets:

Pigeons – Fibonacci melodies
DivSeq – a sequence of clock dividers
PolyDiv – parallel clock dividers, like the Subharmonicon
ResetClk – sequencing helper for DFAM
DualTM – two 32-bit shift registers
EbbAndLfo – mini implementation of MI Tides, with v/oct tracking
EuclidX – AnnularFusion makeover, now includes padding, configurable CV input modulation –
Sequence5 -> SequenceX (8 steps max)

$885.00Excl. VAT
